Smart Switch Installation Guide for Curtain Controller Module

curtain controller

Ready to upgrade your home with smart technology but unsure where to start? Don't worry; we've curated a comprehensive guide to ensure your installation of the Curtain Controller smart switch is smooth and hassle-free. Follow these detailed steps for a seamless and smarter living experience!

Installation Essentials:

Before you begin, gather these essential tools and materials:

  • Insulated screwdrivers (star or flat)
  • Insulated pliers
  • Voltage tester
  • Wire strippers
  • Multimeter (optional)
  • New smart switch
  • Insulation tape
  • Appropriate wires (based on load and requirements)

Ensure you have everything ready to proceed smoothly with the installation of your Curtain Controller smart switch.

Safety Tips for Smart Switch Installation:

  • Read the smart switch instruction manual thoroughly.
  • Turn off the main circuit breaker and double-check with a voltmeter.
  • Use insulated tools and wear protective gloves.
  • Clearly label all wires for easy identification.
  • Ensure your workspace is dry and organised.

These steps will help ensure a safe and successful installation of your smart switch.

Module Compatibility and Console Box Specifications:

When preparing to install the Curtain Controller smart switch, understanding its compatibility and console box requirements is crucial for a successful setup:

Module Name: Curtain Controller

Console Box Size: 78 mm x 78 mm (3" x 3")

Module Specifications:

  • Curtain Controller (L1, L2): 6A

Installation and Wiring Guide:

  • Turn off the power at the breaker box.
  • Label the phase, neutral, earth, and other load wires in the wall console box.
  • Study the terminal labels on the product's wiring sticker to ensure correct wire connections.
  • Connect the wires to their designated terminals as indicated below:
  1. Neutral (N): Powers the device.
  2. Phase (P) UPS/EB: Primary power supply.
  3. Curtain Controller (L1, L2):
         L1: Curtain open (Forward)
         L2: Curtain close (Reverse)
  • Check the wiring setup video for your specific type at home. Ensure all connections are correct, secure, and free of loose strands.
  • Use insulation tape to secure exposed terminals and wire joints.
  • Use a prying tool to carefully remove the glass panel without touching the circuit board.
  • Insert the enclosure into the 2-module metal console box and secure it using the provided screws (M3.5*30mm).
  • Align the top glass with the enclosure and press it firmly to lock it in place, ensuring that all four corners are securely locked.
  • Restore power and test the switch for proper functionality.

If you need any device installation support or assistance, please call or WhatsApp.

Wiring Setup Scenario:

Type 1: Single Power Source (EB or UPS and Common Neutral)

  1. The phase and neutral for the curtain controller are from EB or UPS.
  2. In this scenario, the phase and neutral connections will be as follows:

  • The UPS or EB phase is connected to P, providing power to the device.
  • L1 is connected to the curtain open (Forward) terminal.
  • L2 is connected to the curtain close (Reverse) terminal.
  • The neutral is connected to N.
